Agilent ZORBAX HPLC Columns

Agilent ZORBAX Series

Agilent ZORBAX Stationary Phases and Particle Technology

Agilent ZORBAX HPLC and UHPLC columns comprise a broad range of silica-based stationary phases designed for different chromatographic selectivities and operating conditions. The portfolio combines high-purity porous silica particles with controlled pore structures and specialized bonding chemistries for small-molecule, pharmaceutical and biomolecule separations.

The different ZORBAX stationary-phase families use specific surface modifications, including surface deactivation, sterically protected bonding, bidentate bonding and polar-embedded chemistry. These technologies allow the stationary phase to be selected according to analyte properties, mobile phase conditions, required selectivity and operating pH.

The Agilent ZORBAX Portfolio

ZORBAX Eclipse Plus: The choice for general method development. It offers excellent peak shape for basic, acidic, and neutral compounds with minimal secondary interactions
ZORBAX StableBond (SB): Designed for high stability under extreme, low-pH mobile phases. Ideal for applications utilizing harsh acids at elevated temperatures.
ZORBAX Bonus-RP: Features an embedded polar group that provides unique selectivity for polar compounds and eliminates phase collapse in 100% aqueous mobile phases.
ZORBAX Extend-C18: Engineered with a bidentate silane bonding technology, offering superior column lifetime and performance at high pH (up to pH 11.5).
ZORBAX Original: The classic series from ZORBAX provide a range of stationary-phase selectivities for normal-phase and reversed-phase chromatography

Use the product filters below to select the appropriate Agilent ZORBAX HPLC column according to stationary phase, analyte properties and chromatographic application.

ZORBAX Bonus-RP Series

ZORBAX Eclipse Plus Series

ZORBAX Eclipse XDB Series

ZORBAX Extend-C18 Series

ZORBAX StableBond SB Series

ZORBAX Original Series

1115 Products

Product Number	Description	Price	Specifications

AT-5063-6528

ZORBAX Eclipse XDB Start up Kit, incl. XDB-C18 80Å 5µm 4.6 x 150mm Column, ea.

EUR 1,207.00

Will be procured as soon as possible

Product Number: AT-5063-6528
Manufacturer: Agilent
Brand: ZORBAX Eclipse XDB
Selectivity: C18
Selectivity Manufacturer: XDB-C18
Pore Size: 80 Å
Carbon Load: 10.0 %
Endcapping: yes
Hardware Material: Stainless Steel
Hardware Type: Column Kit
Application: Reversed Phase
USP Code: L1
Temperature Range: 60 °C
pH Range: 2-9
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,207.00

Will be procured as soon as possible

AT-5064-8256

ZORBAX StableBond SB-C18 80Å 5µm, 0.500 x 150mm, ea.

EUR 835.00

Will be procured as soon as possible

Product Number: AT-5064-8256
Manufacturer: Agilent
Brand: ZORBAX StableBond
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 80 Å
Carbon Load: 10.0 %
Endcapping: no
Column Length: 150 mm
Column ID: 0.500 mm
Hardware Material: Stainless Steel
Hardware Type: Capillary Column
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 0.8-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 835.00

Will be procured as soon as possible

AT-5064-8262

ZORBAX StableBond SB-C18 80Å 3.5µm, 0.500 x 150mm, ea.

EUR 927.00

Will be procured as soon as possible

Product Number: AT-5064-8262
Manufacturer: Agilent
Brand: ZORBAX StableBond
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 3.5 µm
Pore Size: 80 Å
Carbon Load: 10.0 %
Endcapping: no
Column Length: 150 mm
Column ID: 0.500 mm
Hardware Material: Stainless Steel
Hardware Type: Capillary Column
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 0.8-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 927.00

Will be procured as soon as possible

AT-5064-8264

ZORBAX StableBond 300SB-C18 300Å 5µm, 0.500 x 150mm, ea.

EUR 835.00

Will be procured as soon as possible

Product Number: AT-5064-8264
Manufacturer: Agilent
Brand: ZORBAX StableBond 300
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 300 Å
Carbon Load: 2.8 %
Endcapping: no
Column Length: 150 mm
Column ID: 0.500 mm
Hardware Material: Stainless Steel
Hardware Type: Capillary Column
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 45 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 835.00

Will be procured as soon as possible

AT-5064-8268

ZORBAX StableBond 300SB-C18 300Å 3.5µm, 0.500 x 150mm, ea.

EUR 927.00

Will be procured as soon as possible

Product Number: AT-5064-8268
Manufacturer: Agilent
Brand: ZORBAX StableBond 300
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 3.5 µm
Pore Size: 300 Å
Carbon Load: 2.8 %
Endcapping: no
Column Length: 150 mm
Column ID: 0.500 mm
Hardware Material: Stainless Steel
Hardware Type: Capillary Column
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 45 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 927.00

Will be procured as soon as possible

AT-5065-9913

ZORBAX StableBond 300SB-C18 300Å 5µm, 0.300 x 5mm Cartridge, pk.5

EUR 559.00

Will be procured as soon as possible

Product Number: AT-5065-9913
Manufacturer: Agilent
Brand: ZORBAX StableBond 300
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 300 Å
Carbon Load: 2.8 %
Endcapping: no
Column Length: 5 mm
Column ID: 0.300 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 45 m2/g
Bonding Type: monomeric
Accessories: Guard Cartridge
Package Size: 5

Questions about the article To the product details

Price:

EUR 559.00

Will be procured as soon as possible

AT-5183-2021

ZORBAX Original ODS 70Å 5µm, 4.6 x 150mm Cartridge Starter Kit (AC System), ea.

EUR 1,359.00

Will be procured as soon as possible

Product Number: AT-5183-2021
Manufacturer: Agilent
Brand: ZORBAX Original
Selectivity: C18
Selectivity Manufacturer: ODS
Particle Size: 5.0 µm
Pore Size: 70 Å
Carbon Load: 20.0 %
Endcapping: yes
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Cartridge Column
Application: Reversed Phase
USP Code: L1
Temperature Range: 60 °C
pH Range: 2-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 300 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,359.00

Will be procured as soon as possible

AT-5183-2022

ZORBAX Original C8 70Å 5µm, 4.6 x 150mm Cartridge Starter Kit (AC System), ea.

EUR 1,399.00

Will be procured as soon as possible

Product Number: AT-5183-2022
Manufacturer: Agilent
Brand: ZORBAX Original
Selectivity: C8
Particle Size: 5.0 µm
Pore Size: 70 Å
Carbon Load: 12.0 %
Endcapping: yes
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Cartridge Column
Application: Reversed Phase
USP Code: L7
Temperature Range: 60 °C
pH Range: 2-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 300 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,399.00

Will be procured as soon as possible

AT-5183-4624

ZORBAX StableBond Method Development Kit, 5µm, 4.6 x 150mm, ea.

EUR 1,519.00

Will be procured as soon as possible

Product Number: AT-5183-4624
Manufacturer: Agilent
Brand: ZORBAX StableBond
Particle Size: 5.0 µm
Pore Size: 80 Å
Endcapping: no
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Temperature Range: 80 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,519.00

Will be procured as soon as possible

AT-5183-4625

ZORBAX Fast StableBond Method Development Kit, 3.5µm, 4.6 x 75mm, ea.

EUR 1,432.00

Will be procured as soon as possible

Product Number: AT-5183-4625
Manufacturer: Agilent
Brand: ZORBAX StableBond
Particle Size: 3.5 µm
Pore Size: 80 Å
Endcapping: no
Column Length: 75 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Temperature Range: 80 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,432.00

Will be procured as soon as possible

AT-5183-4626

ZORBAX Eclipse XDB Method Development Kit, 5µm, 4.6 x 150mm, ea.

EUR 1,519.00

Will be procured as soon as possible

Product Number: AT-5183-4626
Manufacturer: Agilent
Brand: ZORBAX Eclipse XDB
Particle Size: 5.0 µm
Pore Size: 80 Å
Endcapping: yes
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Temperature Range: 60 °C
pH Range: 2-9
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,519.00

Will be procured as soon as possible

AT-5183-4627

ZORBAX Fast Eclipse XDB Method Development Kit, 3.5µm, 4.6 x 75mm, ea.

EUR 1,446.00

Will be procured as soon as possible

Product Number: AT-5183-4627
Manufacturer: Agilent
Brand: ZORBAX Eclipse XDB
Particle Size: 3.5 µm
Pore Size: 80 Å
Endcapping: yes
Column Length: 75 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Temperature Range: 60 °C
pH Range: 2-9
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,446.00

Will be procured as soon as possible

AT-5185-5807

ZORBAX pH Method Development Kit, 5µm, 4.6 x 150mm, ea.

EUR 1,490.00

Will be procured as soon as possible

Product Number: AT-5185-5807
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 5.0 µm
Pore Size: 80 Å
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,490.00

Will be procured as soon as possible

AT-5185-5808

ZORBAX Fast pH Method Development Kit, 3.5µm, 4.6 x 75mm, ea.

EUR 1,490.00

Will be procured as soon as possible

Product Number: AT-5185-5808
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 3.5 µm
Pore Size: 80 Å
Column Length: 75 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,490.00

Will be procured as soon as possible

AT-5185-5809

ZORBAX Aqueous Method Development Kit, 5µm, 4.6 x 150mm, ea.

EUR 1,519.00

Will be procured as soon as possible

Product Number: AT-5185-5809
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 5.0 µm
Pore Size: 80 Å
Column Length: 150 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,519.00

Will be procured as soon as possible

AT-5185-5810

ZORBAX Fast Aqueous Method Development Kit, 3.5µm, 4.6 x 75mm, ea.

EUR 1,446.00

Will be procured as soon as possible

Product Number: AT-5185-5810
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 3.5 µm
Pore Size: 80 Å
Column Length: 75 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,446.00

Will be procured as soon as possible

AT-5185-5920

ZORBAX StableBond SB-C18 80Å 5µm, 1.0 x 17mm MicroBore Guard Cartridge, pk.3

EUR 761.00

Will be procured as soon as possible

Product Number: AT-5185-5920
Manufacturer: Agilent
Brand: ZORBAX StableBond
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 80 Å
Carbon Load: 10.0 %
Endcapping: no
Column Length: 17 mm
Column ID: 1.0 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 0.8-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Accessories: Guard Cartridge
Package Size: 3

Questions about the article To the product details

Price:

EUR 761.00

Will be procured as soon as possible

AT-5185-5921

ZORBAX Eclipse XDB-C18 80Å 5µm, 1.0 x 17mm MicroBore Guard Cartridge, pk.3

EUR 751.00

Will be procured as soon as possible

Product Number: AT-5185-5921
Manufacturer: Agilent
Brand: ZORBAX Eclipse XDB
Selectivity: C18
Selectivity Manufacturer: XDB-C18
Particle Size: 5.0 µm
Pore Size: 80 Å
Carbon Load: 10.0 %
Endcapping: yes
Column Length: 17 mm
Column ID: 1.0 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L1
Temperature Range: 60 °C
pH Range: 2-9
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Accessories: Guard Cartridge
Package Size: 3

Questions about the article To the product details

Price:

EUR 751.00

Will be procured as soon as possible

AT-5185-5922

ZORBAX Bonus-RP 80Å 5µm, 1.0 x 17mm MicroBore Guard Cartridge, pk.3

EUR 771.00

Will be procured as soon as possible

Product Number: AT-5185-5922
Manufacturer: Agilent
Brand: ZORBAX Bonus-RP
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 80 Å
Carbon Load: 9.5 %
Endcapping: yes
Column Length: 17 mm
Column ID: 1.0 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L60
Temperature Range: 60 °C
pH Range: 2-9
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Bonding Type: monomeric
Accessories: Guard Cartridge
Package Size: 3

Questions about the article To the product details

Price:

EUR 771.00

Will be procured as soon as possible

AT-5185-5923

ZORBAX 300Extend-C18 300Å 5µm, 1.0 x 17mm MicroBore Guard Cartridge, pk.3

EUR 703.00

Will be procured as soon as possible

Product Number: AT-5185-5923
Manufacturer: Agilent
Brand: ZORBAX Extend
Selectivity: C18
Selectivity Manufacturer: Extend-C18
Particle Size: 5.0 µm
Pore Size: 300 Å
Carbon Load: 4.0 %
Endcapping: yes
Column Length: 17 mm
Column ID: 1.0 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L1
Temperature Range: 60 °C
pH Range: 2-11.5
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 45 m2/g
Bonding Type: polymeric
Accessories: Guard Cartridge
Package Size: 3

Questions about the article To the product details

Price:

EUR 703.00

Will be procured as soon as possible

AT-5185-5968

Poroshell StableBond 300SB-C18 5µm, 1.0 x 17mm MicroBore Guard Cartridge, pk.3

EUR 724.00

Will be procured as soon as possible

Product Number: AT-5185-5968
Manufacturer: Agilent
Brand: Poroshell 300 StableBond
Selectivity: C18
Selectivity Manufacturer: SB-C18
Particle Size: 5.0 µm
Pore Size: 300 Å
Endcapping: no
Column Length: 17 mm
Column ID: 1.0 mm
Hardware Material: Stainless Steel
Hardware Type: Guard Cartridge
Application: Reversed Phase
USP Code: L1
Temperature Range: 90 °C
pH Range: 1-8
Particle: Silica
Particle Shape: Spherical
Particle Type: Core-Shell
Bonding Type: monomeric
Accessories: Guard Cartridge
Package Size: 3

Questions about the article To the product details

Price:

EUR 724.00

Will be procured as soon as possible

AT-5190-1431

ZORBAX Selectivity Method Development Kit, 1.8µm, 2.1 x 50mm (RRHT 600bar), ea.

EUR 1,873.00

Will be procured as soon as possible

Product Number: AT-5190-1431
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 1.8 µm
Pore Size: 80 Å
Column Length: 50 mm
Column ID: 2.1 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,873.00

Will be procured as soon as possible

AT-5190-1432

ZORBAX pH Method Development Kit, 1.8µm, 2.1 x 50mm (RRHT 600bar), ea.

EUR 1,892.00

Will be procured as soon as possible

Product Number: AT-5190-1432
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 1.8 µm
Pore Size: 80 Å
Column Length: 50 mm
Column ID: 2.1 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,892.00

Will be procured as soon as possible

AT-5190-1433

ZORBAX Selectivity Method Development Kit, 1.8µm, 4.6 x 50mm (RRHT 600bar), ea.

EUR 1,892.00

Will be procured as soon as possible

Product Number: AT-5190-1433
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 1.8 µm
Column Length: 50 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,892.00

Will be procured as soon as possible

AT-5190-1434

ZORBAX pH Method Development Kit, 1.8µm, 4.6 x 50mm (RRHT 600bar), ea.

EUR 1,892.00

Will be procured as soon as possible

Product Number: AT-5190-1434
Manufacturer: Agilent
Brand: ZORBAX
Particle Size: 1.8 µm
Pore Size: 80 Å
Column Length: 50 mm
Column ID: 4.6 mm
Hardware Material: Stainless Steel
Hardware Type: Method Development Kit
Application: Reversed Phase
Particle: Silica
Particle Shape: Spherical
Particle Type: Fully Porous
Surface Area: 180 m2/g
Package Size: 1

Questions about the article To the product details

Price:

EUR 1,892.00

Will be procured as soon as possible

Agilent ZORBAX Stationary Phases and Particle Technology

Filter products
